Audio Dynamics 1200.4 amplifier "DEMO VIDEO IN LAST SLIDE"
Regular price
$800.00 USD
Regular price
Sale price
$800.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
| Continuous Power | 220W x 4 @ 4 ohms |
| 14.4V Supply Voltage | 340W x 4 @ 2 ohms |
| Bridged | 680W x 2 @ 4 ohms |
| Frequency Response | 10Hz – 35KHz |
| Input Sensitivity | 0.2V to 6V |
| Recommended Fuse Ratings | 80A @ 4 ohms / 125A @ 2 ohms |
| Filter Modes | High Pass – Low Pass – Band Pass |
| High Pass Filter | Ch 1+2: 20Hz – 5KHz |
| At 12dB/Oct Slope | Ch 3+4: 50Hz – 5KHz |
| Linkwitz-Riley | |
| Low Pass Filter | Ch 1+2: 20Hz – 5KHz |
| At 12dB/Oct Slope | Ch 3+4: 50Hz – 5KHz |
| Linkwitz-Riley | |
| Detented Filter Potentiometers | 41 Click-in-Place Frequencies |
| Remote Level Control w/ Clip Indicator | Included |
| Height | 2.64 in / 67 mm |
| Width | 7.54 in / 191.4 mm |
| Length | 11.82 in / 300.2 mm |
| Net Weight |
9 lb / 4.08 kg |
Materials
Materials
3/4" MDF PLYOOD WITH BEDLINER COATING
Shipping
Shipping
FEDEX FULLY INSURED
Dimensions
Dimensions
SHIPPING DIMENSIONS 50"W X 10"D X 20" H
