Sundown Audio 6.5" U series dual 2 ohm

SUNDOWN AUDIO U-65 6.5" Subwoofer D2 | 400W RMS - 2 OHM

Introducing the Sundown Audio U-6.5 Subwoofers with D2 Voice Coil!



Prepare yourself for an audio experience that will redefine your expectations. The Sundown Audio U-6.5 Subwoofers with D2 Voice Coil are here to revolutionize your sound system with their exceptional performance and unmatched power.



Equipped with a robust 400W RMS (Root Mean Square) driver, these subwoofers deliver an extraordinary level of performance. Whether you crave earth-shattering bass or flawlessly crisp lows, the U-6.5 Subwoofers are engineered to exceed your every desire.



The D2 Voice Coil configuration of these subwoofers provides you with unparalleled flexibility in optimizing your audio setup. With its dual 2-ohm voice coils, you have the freedom to customize your system and extract the most from your audio experience.



What sets the U-6.5 Subwoofers apart is the cutting-edge "W" surround technology, inspired by the successful SD-4 model. This surround is meticulously designed using Finite Element Analysis (FEA), ensuring optimal mechanical performance. Its increased stiffness near the limits prevents damage and ensures the subwoofers can handle even the most demanding audio conditions.



In perfect harmony with the surround, Sundown Audio is developing a specialized spider that is tailored specifically for the U-6.5SW model. This intricate combination of components guarantees flawless performance and creates an audio experience that will leave you in awe.



When it comes to excursion capabilities, the U-6.5 Subwoofers with D2 Voice Coil offer an impressive one-way linear X-max of 19mm, reaching an astonishing 70% BL. The exceptional excursion is backed by a substantial amount of motor force, resulting in unparalleled sonic precision and impact.



Unlike previous models, the U-6.5 Subwoofers are not limited by depth constraints. Sundown Audio has spared no effort in designing a subwoofer that delivers outstanding performance without sacrificing size or form factor.



Get ready to redefine your audio experience with the Sundown Audio U-6.5 Subwoofers with D2 Voice Coil. Elevate your sound system, make a statement, and immerse yourself in the true essence of music. Prepare to unleash the power of exceptional sound!







FEATURES

RMS: 400W

Black Aluminum 1.753” voice coil former for superior heat dissipation

High Temperature Round-Wire Copper voice coil

Double stitched surround

Heavy duty cast basket

Spring loaded terminals accept up to 8 gauge

Stitched-on heavy-duty tinsel leads

Solid pole with vent channels and aluminum shorting ring cap

Rear drilled gap-venting

Magnet ID shorting ring

Top-Plate Cooling Channels

Optimized for small ported enclosures

U-6.5SW



T/S SPECS U-6.5SW" D2

RE (Ohms) 4.0586 6.6274

FS (Hz) 41.9533 38.6925

VAS (L) 2.9053 3.7701

Qes 0.5238 0.5005

Qms 8.5834 7.2470

Qts 0.4937 0.4681

Le (mH) 4.0112 5.5892

BL (NA) 16.7428 20.0082

Mms (Grams) 137.2546 124.3518

Cms (uM/N) 104.8528 136.0613

Sens (dB @ 1w/1m) 77.8706 78.1460



ENCLOSURE SPECS



Ported Enclosure

Size: .25-.35 cuft net

Port Area: 4-5 sqin

Port Tuning: 35hz -40hz



Sealed Enclosure

Size: 0.125-0.2 cuft net

Displacement: .04 cu. ft.



Physical Dimensions



Depth: 5.71"



Outside Diameter: 7.17"

Cutout: 5.94"
