Sundown Audio SIA 2500D

Sundown Audio SIA 2500D Mono Block Amplifier

SPECIFICATIONS

2500 x 1 Watts RMS @ 1ohm

2500 × 1 Watts RMS @ 2 ohm

2000 × 1 Watts RMS @ 4 ohm

Dimensions

Length - 7.25"

Width - 7.25"

Height - 2.45'

FEATURES

Input Sensitivity 200mV MAX

Minimum Supply Voltage 10.5V

Maximum supply voltage 15.5V

Signal-to-noise ratio: 108dB

Frequency Response: 10HZ to 20KHZ (-3dB)

Crossover:

H.P.F (High-pass Filter): 10 to 1KHz (-12dB/8) Variable

L.P.F (Low-pass Filter): 40Hz to 20KHz (-12dB/8) Variable

Thermal Managament: Smart cooler (fan powered by temperature or audio, with 3 speeds)

Input Impedance: 56k ohms

Protection System: Output Short/High/Low supply voltage/Thermal protection

Minimum supply voltage : 9VDC

Maximum supply voltage : 16VDC

Working Voltage 10.5V - 15.5V DC
